Tricotex 80/400
TRICOTEX® 80/400 Geotextile
TRICOTEX® 80/400 is a very high-performance geotextile made of PP tapes for demanding construction projects. The material offers very high tensile strength and supports long-term stabilisation of subgrades. Its structure improves load distribution and prevents the mixing of different soil layers. This enables durable and safe construction, even for applications with particularly high loads.
Application
Traffic areas, haul roads, road construction and projects with very high loading requirements.
Brand
TRICOTEX
Material
PP - BAENDCHEN
Thickness
EN 9863-1 (bei 2 kN/m2) = 1.2 mm
Material weight
EN 9864 = 400 g/m2 g/m²
Tensile strength (longitudinal)
EN 10319 = 80 kN/m
Tensile strength (transverse:)
EN 10319 = 80 kN/m
Elongation (longitudinal)
EN 10319 = 96 %
Elongation (transverse)
EN 10319 = 72 %
Punch penetration force
EN ISO 12236 = 9.5 kN
Flow rate perpendicular to the plane
EN ISO 11058 = 10 l/m2/s
Characteristic opening width
EN ISO 12956 = 0.13 mm
Weather resistance
EN 12224 (nach 50MJ) = 100 %
1 Artikel
Reset filters
Filter
Item
Width m
Length m
Availability
SU
Price / SU in CHFexcl. VAT
- Item 60001.080Width
m 5.2Length
m 100AvailabilitySU 520 m2Price / SU in CHF excl. VATEtiketten druckenAdd item to the shopping cart
